- By:
- Wang, Tianzhao ; Lim, Yong Chae ; Ojo, Sammy A; Feng, Zhili
- Page Number:
- 233-241
- Book Title:
- Friction Stir Welding and Processing XIII
- Publication Date:
- March 12, 2026
- Publisher Location:
- Springer, Cham, Switzerland
- Conference Name:
- TMS 2025: TMS Annual Meeting & Exhibition
- Conference Location:
- Las Vegas, Nebraska, United States of America
- Conference Sponsor:
- The minerals, metals, and materials society
- View DOI Listing:
- https://doi.org/10.1007/978-3-031-80896-8_20
Abstract
Friction self-piercing riveting (F-SPR), as a solid-state joining process that generates frictional heat during the process, was utilized to join a 3 T configuration of low-ductility AA7075-AA7075-AA6022 sheets. A multi-step F-SPR process was employed to precisely control the mechanical interlocking and solid-state joining, ensuring a strong joint formation. With control of the plunge depth when the transition from rivet penetration to rivet flaring, two joining conditions were developed to assess mechanical joint integrity: one bearing deep penetration with a smaller interlock, and the other yielding a shallow penetration with a larger interlock. Both strategies met the criteria for a sound rivet joint. Customized lap shear tensile configurations were designed to assess the joint strength at interface between first and second layers, as well as between second and third layers. Both conditions demonstrated great joint strength between the first and second layers, while deeper penetration approach showed stronger solid-state joint, leading to improved joint strength between the second and third layers.
