Genesis of a novel high-rate composite manufacturing process using large-scale additive manufacturing – compression molding (AM-CM) system: Possibilities and limitations∗

Abstract

Oak Ridge National Laboratory (ORNL) has developed a highly automated manufacturing process for thermoplastic composites that combines the benefits of Additive Manufacturing and Compression Molding (AM-CM) to produce high-performance functional composite structures at automotive production rates. The AM-CM process creates highly precise preforms by additively placing extruded fiber-filled polymers (with controlled fiber orientations and multi-material configurations) in the desired mold location before undergoing a secondary compression molding process immediately before the preform cools down. Preforms can be in the form of short, long-chopped, or continuous fiber-filled thermoplastic polymers (e.g., CF/GF-filled ABS, PC, LM-PAEK, etc.). The AM-CM process combines the benefits of controlled fiber alignment, that is only achievable in AM-printed parts with the classical CM process, which eliminates porosity and good surface finish. A preform created using AM-CM can integrate various materials to enable additional architectural functionalities, including over-molding, selective stiffening, and the incorporation of electrically or thermally conductive channels. All these advantages come with a fast part production cycle time. The AM-CM process can manufacture multi-material, multi-functional parts in under 3 min, starting from raw material (pellets) to the final product. The novel AM-CM process offers superior microstructural control and enhanced multi-functionality previously unattainable with any other traditional high-rate thermoplastic composite manufacturing method. This work covers the manufacturing concept, system development, materials and applications of AM-CM process in detail.
