Investigation of irradiation damage and heat deposition: a comparative analysis for HEU-to-LEU conversion in HFIR

Abstract

The planned conversion of the High Flux Isotope Reactor (HFIR) at Oak Ridge National Laboratory from highly enriched uranium (HEU) to low-enriched uranium (LEU) fuel requires detailed evaluation of experiment-relevant parameters to ensure continued performance for materials testing and isotope production. This study presents the first comprehensive assessment of displacements per atom (dpa) and heat deposition rates in target materials within the HFIR flux trap with both HEU and candidate LEU core configurations. Seven analyses were conducted to evaluate key performance metrics, including fast neutron flux distribution, cross section response functions, cross section data, and local dpa and heat deposition rates using mesh- and cell-based tallies. Simulations employed Shift, Monte Carlo N-Particle (MCNP), and the HIFR Controller (HFIRCON) tool suite for high-fidelity transport and depletion modeling. The LEU designs—using U3Si2-Al dispersion fuel and operating at 95 MW—were compared to the current 85 MW HEU configuration. Results show that while the candidate LEU cores exhibit higher dpa rates due to a harder spectrum and extended cycle lengths, they also demonstrate reduced heat deposition rates in irradiation experiments, primarily due to increased gamma self-shielding from higher 238U content in the core. These findings confirm that LEU conversion can maintain HFIR’s materials irradiation capabilities but may require redesigning existing experimental hardware.
