RidgeAlloy: A high pressure die casting alloy that captures the approaching wave of automotive body sheet scrap

Abstract

Oak Ridge National Laboratory (ORNL) has recently launched an effort to economically expand the North American aluminum supply chain by designing and developing a new family of Al-Mg-Si-Fe-Mn structural die cast aluminum alloys that can be made from up to 100% mixed 5xxx and 6xxx series automotive post-consumer sheet scrap and do not require heat treatment. The goal is to develop an alloy capable of capturing the approaching scrap wave of aluminum sheet intensive vehicles (in the 2030’s) into integrated structural high pressure die castings, rather than down-cycling these high-grade sheet alloys into non-structural castings. ORNL discovered a significant gap in the commercial thermodynamic databases that were unable to predict the trends of a key primary intermetallic phase as a function of composition. Experiments were performed to correct this gap and to create a unique, corrected quaternary database for Al-Mg-Si-Fe. High throughput computational methods, including solidification simulations, were used to identify a composition volume capable of avoiding this embrittling primary intermetallic phase, even at higher Fe + Si contents. Laboratory scale castings validated the thermodynamic and solidification predictions and resulted in lab-cast alloys with little primary intermetallic, and which met or exceeded structural casting properties requirements for yield strength and ductility. An accelerated demonstration of an HPDC automotive part was conducted in collaboration with two U.S. small businesses. Ingots made from 100% recycled 5xxx and 6xxx series scrap (plus Fe) were used to die cast one variant of this new family of Al-Mg-Si-Fe-Mn alloys (with high Si + Fe content) into a mid-sized HPDC structural-type automotive component. The HPDC alloy demonstration part showed good properties (especially ductility) and good castability for a complex component.
